Condition : Excellent
Year : 2015
Manufacturer :SANY
Model : SY215C
Hours : 8,600 h

Description
Key Parameters:
Operating Weight: 21900kg
Engine Model: Mitsubishi 6D34TL
Rated Power: 114/2050kW/rpm
Std.Bucket:0.93m
Selling Points:
Dual-pump, dual-circuit power control system|Positive flow controlled hydraulic system|Reinforced X-frame

Engine: Engine Model Mitsubishi 6D34TL
Displacement 5.87L
Rated Power 114/2050kW/rpm

Operating Weight:
Std. Operating Weight 21900kg
Hydraulic System
Relief Valve - Implement Circuit 34.3mpa
Relief Valve - Travel Circuit 34.3mpa
Relief Valve - Swing Circuit 25.5mpa
Relief Valve - Pilot Circuit 3.9mpa

Service Capacities:
Fuel Tank Capacity 340L
Hydraulic Tank Capacity 239L
Engine Oil 22L
Cooling System 29L
Final Drive (each) 5.0L
Swing Drive (each) 4L

Undercarriage:
Track Shoes Number 47
Carrier Roller - Perside 2
Track Roller - Perside7

Working Range:
Max.Digging Force - Bucket 138KN
Max.Digging Force - Arm 103kN
Max.Digging Height 9600mm
Max.Digging Depth 6600mm
Max.Vertical Digging Depth 6255mm
Max. Excavating Distance 10280mm
Min. Swing Radius 3730mm
Height at Min. Swing Radius 7680mm

Transmission:
Travel Speed - Highest5.4km/h
Travel Speed - Lowest3.3km/h
Swing Speed11rpm
Gradeability70%/35 degree
Std. Operating Weight47.4kPa

Dimensions:
Transportation Length 9680mm
Transportation Width 2980mm
Transportation Height 3440mm
Upper Body Width 2875mm
Cab Height 3075mm
Std.Track Width 600mm
Track Gauge 2380mm
Min.Ground Clearance 440mm
